FEP-20-50NP
Description
Description Parameter Manufacturer's type designation FEP-20-NPFEP-25-NPFEP-30-NPFEP-35-NPFEP-40-NPFEP-45-NPFEP-50-NPLoad capacity/rated loadkg2000250030003500400045005000Service weight incl. batterykg3790394245734748621065356965Free lift mm140140145145150150150Load centre distancemm500500500500500500500Fork dimensions (s/e/l)s/e/l(mm)40/122/107040/122/107045/122/107050/122/107050/122/107050/150/107055/150/1070Turning radius mm2100210022202220263526352635Travel speed,laden/unladenkm/h18/1918/1918/1918/1918/1818/1818/18Max.Gradient performance,laden/unladen%20/2020/2020/2015/2015/2015/2015/20Battery voltage,nominal capacity K5 V/Ah80/280/32480/280/32480/280/324/41280/280/324/41280/53680/53680/53680/200/268/400/53680/684/804/912Motor control mode AC/PMSMAC/PMSMAC/PMSMAC/PMSMPMSMPMSMPMSM
Read more
Finance the purchase of this product
with
Speak with an advisor now
Speak with an advisor now
Available listings
-
TCR Logismaq
Inquire
Available for financing
Product description
Description
Parameter
| Manufacturer's type designation | FEP-20-NP | FEP-25-NP | FEP-30-NP | FEP-35-NP | FEP-40-NP | FEP-45-NP | FEP-50-NP | |
| Load capacity/rated load | kg | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 |
| Service weight incl. battery | kg | 3790 | 3942 | 4573 | 4748 | 6210 | 6535 | 6965 |
| Free lift | mm | 140 | 140 | 145 | 145 | 150 | 150 | 150 |
| Load centre distance | mm | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
| Fork dimensions (s/e/l) | s/e/l(mm) | 40/122/1070 | 40/122/1070 | 45/122/1070 | 50/122/1070 | 50/122/1070 | 50/150/1070 | 55/150/1070 |
| Turning radius | mm | 2100 | 2100 | 2220 | 2220 | 2635 | 2635 | 2635 |
| Travel speed,laden/unladen | km/h | 18/19 | 18/19 | 18/19 | 18/19 | 18/18 | 18/18 | 18/18 |
| Max.Gradient performance,laden/unladen | % | 20/20 | 20/20 | 20/20 | 15/20 | 15/20 | 15/20 | 15/20 |
| Battery voltage,nominal capacity K5 | V/Ah | 80/280/324 | 80/280/324 | 80/280/324/412 | 80/280/324/412 | 80/536 | 80/536 | 80/536 |
| 80/200/268/400/536 | 80/684/804/912 | |||||||
| Motor control mode | AC/PMSM | AC/PMSM | AC/PMSM | AC/PMSM | PMSM | PMSM | PMSM |
