PTE15Q3
Description
Description Parameter Manufacturer`s type designation PTE15Q3-APTE15Q3-BLoad Capacity / rated loadQ(kg)1500Load centre distance mm600Lift heightmm115Fork dimensionss/e/l (mm)50/160/1150Fork spreadmm540 / 685Aisle width for pallets 800X1200 lengthwaysmm2128Turning radiusmm1358Travel speed, laden/ unladenkm/h4.2 / 4.5Max. gradeability, laden/ unladen%7 / 16Battery voltage, nominal capacity K5V/Ah24/20 ( 30 / 50 )24/20 ( 40 )
Read more
Finance the purchase of this product
with
Speak with an advisor now
Speak with an advisor now
Available listings
-
TCR Logismaq
Inquire
Available for financing
Product description
Description
Parameter
| Manufacturer`s type designation | PTE15Q3-A | PTE15Q3-B | |
| Load Capacity / rated load | Q(kg) | 1500 | |
| Load centre distance | mm | 600 | |
| Lift height | mm | 115 | |
| Fork dimensions | s/e/l (mm) | 50/160/1150 | |
| Fork spread | mm | 540 / 685 | |
| Aisle width for pallets 800X1200 lengthways | mm | 2128 | |
| Turning radius | mm | 1358 | |
| Travel speed, laden/ unladen | km/h | 4.2 / 4.5 | |
| Max. gradeability, laden/ unladen | % | 7 / 16 | |
| Battery voltage, nominal capacity K5 | V/Ah | 24/20 ( 30 / 50 ) | 24/20 ( 40 ) |
