FEP-30/35/38P
Description
Description Parameter Manufacturer's type FEP-30PFEP-35PFEP-38PLoad capacityQ(kg）300035003800Service weight incl.kg428046604980Lift heightmm300030003000Overall length mm368837553755Overall width (Frame/tires)mm123012301230Fork dimension（s/e/l）mm45/122/107050/122/107050/122/1070Turning radiusmm236024702470Travel speed,laden/unladenkm/h15/1615/1615/16Lift speed,laden/unladenmm/s420/520400/500400/500Drive motor rating S2 60 minkw152020Battery voltage, capacity K5V/Ah 76.8/206(277/412/554) 76.8/206(277/412/554) 76.8/206(277/412/554)
Read more
Finance the purchase of this product
with
Speak with an advisor now
Speak with an advisor now
Available listings
-
TCR Logismaq
Inquire
Available for financing
Product description
Description
Parameter
| Manufacturer's type | FEP-30P | FEP-35P | FEP-38P | |
| Load capacity | Q(kg） | 3000 | 3500 | 3800 |
| Service weight incl. | kg | 4280 | 4660 | 4980 |
| Lift height | mm | 3000 | 3000 | 3000 |
| Overall length | mm | 3688 | 3755 | 3755 |
| Overall width (Frame/tires) | mm | 1230 | 1230 | 1230 |
| Fork dimension（s/e/l） | mm | 45/122/1070 | 50/122/1070 | 50/122/1070 |
| Turning radius | mm | 2360 | 2470 | 2470 |
| Travel speed,laden/unladen | km/h | 15/16 | 15/16 | 15/16 |
| Lift speed,laden/unladen | mm/s | 420/520 | 400/500 | 400/500 |
| Drive motor rating S2 60 min | kw | 15 | 20 | 20 |
| Battery voltage, capacity K5 | V/Ah | 76.8/206(277/412/554) | 76.8/206(277/412/554) | 76.8/206(277/412/554) |
