PSE10L/15L-C
Description
Description Parameter Manufacturer`s type designation PSE10L-CPSE15L-C 1600360016003600Load Capacity / rated loadt1.01.6Service weightkg420560350592Lowered mast heightmm2057233219802282Fork dimensionss/e/l (mm)60 /180 /115060 /180 /1150Aisle width for pallets 1000X1200 crosswaysmm22932324Travel speed, laden/ unladenKm/h4.33 / 4.674.30 / 4.65Max. gradeability, laden/ unladen%5 / 105 / 10Battery voltage, nominal capacity K5V /Ah2x12 / 752x12 / 75
Read more
Finance the purchase of this product
with
Speak with an advisor now
Speak with an advisor now
Available listings
-
TCR Logismaq
Inquire
Available for financing
Product description
Description
Parameter
| Manufacturer`s type designation | PSE10L-C | PSE15L-C | |||
| 1600 | 3600 | 1600 | 3600 | ||
| Load Capacity / rated load | t | 1.0 | 1.6 | ||
| Service weight | kg | 420 | 560 | 350 | 592 |
| Lowered mast height | mm | 2057 | 2332 | 1980 | 2282 |
| Fork dimensions | s/e/l (mm) | 60 /180 /1150 | 60 /180 /1150 | ||
| Aisle width for pallets 1000X1200 crossways | mm | 2293 | 2324 | ||
| Travel speed, laden/ unladen | Km/h | 4.33 / 4.67 | 4.30 / 4.65 | ||
| Max. gradeability, laden/ unladen | % | 5 / 10 | 5 / 10 | ||
| Battery voltage, nominal capacity K5 | V /Ah | 2x12 / 75 | 2x12 / 75 |
