PWB-150/200/300
Description
Description Parameter Manufacturer`s type designation PWB-150PWB-200PWB-300Load Capacity / rated loadkg150020003000Service weightkg130139185Lift heightmm115Fork dimensions DIN ISO 2331s/e/l (mm)50 / 160 / 1150Aisle width for pallets 800X1200 lengthwaysmm2005Travel speed, laden/ unladenKm/h4.0 / 4.44.0 / 4.43.7 / 4.2Max. gradeability, laden/ unladen%6 / 207 / 206 / 20Battery voltage, nominal capacity K5V/Ah24/20 (24/40; 24/60)48/20 (48/10)48/20 (48/30)
Read more
Finance the purchase of this product
with
Speak with an advisor now
Speak with an advisor now
Available listings
-
TCR Logismaq
Inquire
Available for financing
Product description
Description
Parameter
| Manufacturer`s type designation | PWB-150 | PWB-200 | PWB-300 | |
| Load Capacity / rated load | kg | 1500 | 2000 | 3000 |
| Service weight | kg | 130 | 139 | 185 |
| Lift height | mm | 115 | ||
| Fork dimensions DIN ISO 2331 | s/e/l (mm) | 50 / 160 / 1150 | ||
| Aisle width for pallets 800X1200 lengthways | mm | 2005 | ||
| Travel speed, laden/ unladen | Km/h | 4.0 / 4.4 | 4.0 / 4.4 | 3.7 / 4.2 |
| Max. gradeability, laden/ unladen | % | 6 / 20 | 7 / 20 | 6 / 20 |
| Battery voltage, nominal capacity K5 | V/Ah | 24/20 (24/40; 24/60) | 48/20 (48/10) | 48/20 (48/30) |
