RRS-150/180
Description
Description Parameter Manufacturer RRS-150RRS-180Load capacity / rated loadkg15001800Lift mm60006000Overall lengthmm20852085Overall widthmm10901090Turning radiusmm16051755Aisle width for pallets 1100 x 1100 mm26502700Travel speed, load/unloadkm/h9.5 / 9.59.5 / 9.5Lift speed, load/unloadmm/s0.30 / 0.560.30 / 0.56Max. gradeability, load/unload%10 / 1010 / 10Drive motor rating S2 60 minkW4.94.9Lift motor rating S3 15%kW88Battery voltage, nominal capacity K5V/Ah48 / 28048 / 375
Read more
Finance the purchase of this product
with
Speak with an advisor now
Speak with an advisor now
Available listings
-
TCR Logismaq
Inquire
Available for financing
Product description
Description
Parameter
| Manufacturer | RRS-150 | RRS-180 | |
| Load capacity / rated load | kg | 1500 | 1800 |
| Lift | mm | 6000 | 6000 |
| Overall length | mm | 2085 | 2085 |
| Overall width | mm | 1090 | 1090 |
| Turning radius | mm | 1605 | 1755 |
| Aisle width for pallets 1100 x 1100 | mm | 2650 | 2700 |
| Travel speed, load/unload | km/h | 9.5 / 9.5 | 9.5 / 9.5 |
| Lift speed, load/unload | mm/s | 0.30 / 0.56 | 0.30 / 0.56 |
| Max. gradeability, load/unload | % | 10 / 10 | 10 / 10 |
| Drive motor rating S2 60 min | kW | 4.9 | 4.9 |
| Lift motor rating S3 15% | kW | 8 | 8 |
| Battery voltage, nominal capacity K5 | V/Ah | 48 / 280 | 48 / 375 |
