HD electric lifting table

The fixed double scissors lift is a stationary, electro-hydraulic lifting device designed for workshops and garages, primarily used for vehicle maintenance and repair. This equipment employs a double scissor mechanism to elevate vehicles, providing a stable and efficient solution for accessing the undercarriage. Key features of this lift include a low profile design with a minimum height of 105 mm, allowing easy access under vehicles without the need for ramps. It is equipped with adjustable front extensions measuring 456 mm and convertible run-up ramps of 267 mm, resulting in a total length of 2,270 mm, which accommodates longer vehicles. The lift has a high load capacity, supporting vehicles weighing up to 3,500 kg (7,716.2 lb), making it versatile for various vehicle types. Installation options for the lift include floor or recessed installation, with an optional inground frame available for flush-floor installation. It complies with the EN 1493 standard for reversible load, ensuring safe operation during lifting and lowering. The standard supply includes a control unit connection of up to 2 m and four 40 mm rubber pads. For detailed technical documentation, including installation and maintenance guidelines, refer to the product catalog provided by M & B Engineering S.r.l.
